Features
● Microprocessor temperature controller with LCD screen ensures precise and reliable control, easy to operate.
● No angle in bath chamber, easy to clean.
● With interface to external water bath.
● Easy to set Adjustable Timer. (1 minute to 5,999 minutes)
● Maintenance-free operation with easy to clean surface.
● Both heater and bath chamber are made of corrosion-resistant stainless steel.
● Drain valve makes emptying of bath water fast and easy for cleaning and moving.
● Programming setting function with 7 periods and 9 steps for each period, which means there are 63 programmable steps in total.
Safety
● Audible and visible alarm for temperature and water level.
● Preset On/Off function.
● Built-in power interruption protection function, automatic run after power interruption.
● Heater alarm, sensor alarm, upper and lower temperature alarm.
● Temperature deviation alarm.
● Over current protection alarm.
Option
● Available RS-485 or USB ports for data collection.
Specification
Model | Temperature range | Precision | Liquid tank opening depth (mm) | Chamber volume | Power requirements | Pump (flux) | Power Consumption |
BP-5H | RT+5～150℃ | ±0.1 | 150×160/150 | 6.7L | AC220V 50HZ | 8L/min | 1050W |
BP-13H | RT+5～150℃ | ±0.1 | 240×170/150 | 10.9L | 8L/min | 1050W |
BP-19H | RT+5～150℃ | ±0.1 | 330×300/150 | 22.5L | 8L/min | 1050W |
BP-31H | RT+5～150℃ | ±0.2 | 240×170/200 | 14.5L | 8L/min | 1050W |
●All test data are tested in a 25°C environment
Provided for precise and constant temperature and auxiliary heating in colleges industrial and mining enterprises and scientific research departments.
